Technical Details

• Features Locking Feature
• Color White
• Mounting Type Panel Mount
• Number of Positions 3
• Pitch 0.394" (10.00mm)
• Type Plug, Female Sockets
• Operating Temperature -35°C ~ 85°C
• Termination Style Solder
• Material Flammability Rating UL94 V-0
• Current - IEC 25A
• Number of Levels 1
• Positions Per Level 3
• Plug Wire Entry 180°
• Housing Material Polyamide (PA66), Nylon 6/6
• Contact Tail Length 0.138" (3.50mm)
• Insulation Height 0.575" (14.60mm)
• Current - UL 23 A
• Voltage - IEC 250 V
• Voltage - UL 600 V
• ECCN EAR99
• HTSUS 8536.90.4000
• Moisture Sensitivity Level (MSL) 1 (Unlimited)
• RoHS Status ROHS3 Compliant
